PNEUMATIC/ELECTRIC CYLINDER GUIDEWAY
The compact PCG/ECG Unit provides robust guidance for both pneumatic and electric actuators, and it does this in compliance with the ISO 15552 standard. The units have been developed on the basis of standard dimensions and are available in bore sizes 32 through 63 with a maximum stroke length of 500 mm. Other information and stroke lengths are available upon request.
- High loads permissible
- High rigidity with compact dimensions
- Easy installation and maintenance
- Long service life
- Compatible elements
- Actuators are not included
